Classical off the shelves analyses in SDT (EMA, numerical modal analysis, shape correlation, …) are integrated with automated report generation.
Tables, animations, pictures, text… can then be easily analyzed with main results displayed at the same time and same place with a unified formatting.
Default output formats are Microsoft Word or Power Point. Depending on the data type, we also support Excel, HTML, LaTeX, MarkDown…
Formatting and exporting strategies are tunable, so that we can build dedicated outputs using customized templates.
The above video illustrates this functionality applied to the Experimental Modal Analysis results. The default report shows
- Text describing the analysis context (number of sensors/actuators, identification options, number of modes…)
- AutoMAC matrix
- A Modal Indicator Function
- The quality table
- The identified mode shape animations
Sections and captions can be separately activated by checking the desired boxes and captions can be edited on the fly!
